Supported CPU

Supports 10th Gen Intel Core Processors, Pentium Gold and Celeron Processors
Processor socket LGA1200

Chipset

Intel H510 Chipset

Form Factor

m-ATX Form Factor
9.3 in. x 7.95 in. (23.6 cm x 20.2 cm)

Audio

Realtek ALC897/ ALC892 Codec
7.1-Channel High Definition Audio

PCI

1x PCIe 3.0 x16 slot (From CPU)
1x PCIe 3.0 x1 slot (From PCH)

M.2 Socket

1x M.2 slot (Key M, from H510 chipset)

Type

DDR4

Slots

2x DDR4 memory slots

Supported Memory

Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel CPU (by JEDEC & POR)
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel Extreme Memory Profile (XMP)

Maximum Memory

Up to 64GB

Graphics

1x VGA port, supports a maximum resolution of 2048x1536 60Hz, 1920x1200 60Hz
1x HDMI 1.4 port, supports a maximum resolution of 4K 30Hz

HDMI

1x HDMI 1.4 port

VGA (s)

1x VGA port

USB (s)

Intel H510 Chipset
4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector)
6x USB 2.0 ports (4 Type-A ports on the back panel, 2 ports available through the internal USB 2.0 connector)

LAN Port (s)

1x Realtek RTL8111 Gigabit LAN controller

Supported Storage

4x SATA 6Gb/s ports (From H510 Chipset)
1x M.2 slot (Key M, from H510 chipset)
Supports up to PCIe 3.0 x4
Supports SATA 6Gb/s
Supports 2242/ 2260/ 2280 storage devices

Audio

1x Front panel audio connector

Internal I/O Ports

1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
4x SATA 6Gb/s connectors
1x USB 2.0 connector (support additional 2 USB ports)
1x USB 3.2 Gen 1 5Gbps connector (support additional 2 USB ports)
1x 4-pin CPU fan connector
1x 4-pin system fan connector
1x Front panel audio connector
2x System panel connectors
1x Serial port connector
1x TPM module connector
1x Chassis Intrusion connector
1x Clear CMOS jumper

TPM (Trusted Platform Module )

1 x TPM module connector

Manufacturing Warranty

03 Years
